This document introduces the features and characteristics of 3 air conditioner products: KFR-50LW/09FZBpC, KFR-72LW/09FZBpC and KFR-72LW/09FZBpC(a).
This manual provides step‑by‑step instructions for installing Hisense split‑type air conditioners, including safety warnings, required tools, and wiring guidelines. It also describes the components of the indoor and outdoor units and how to connect the refrigerant piping.
Additional sections cover remote‑control operation, mode selection, troubleshooting tips, and the full technical specifications of each model. The document is intended for qualified installers and includes voltage and grounding requirements. This manual is written in Chinese.
| Model | KFR-50LW/09FZBpC / KFR-72LW/09FZBpC |
|---|---|
| Rated voltage | AC 220 V |
| Cooling capacity (kW) | 1.5 kW (50 kW model) – 6.4 kW (72 kW model) |
| Heating capacity (kW) | 6.1 kW (50 kW model) – 8.6 kW (72 kW model) |
| Indoor unit noise level | 32 dB – 35 dB |
| Outdoor unit weight | 41 kg – 85 kg |
No. The outdoor unit should not be placed where it can be directly splashed by seawater or near sulfur‑containing hot springs to avoid severe corrosion.
The manual uses a specific warning symbol (人) to highlight content that could cause personal injury or equipment damage if mishandled.
