PT-U1X86, PT-U1X66, PT-U1S66 are three projector products produced by Panasonic, support RGB, RGB1, RGB2, YPBPR, VGA60/525P, SXGA and other input formats, can be controlled through RS-232C
This manual provides detailed instructions for operating the Panasonic PT-U1X86, PT-U1X66, and PT-U1S66 liquid crystal projectors. It describes the front‑panel controls, menu navigation, input selections (RGB, YPBPR, S‑Video), audio connections, and RS‑232C communication settings.
Technical data such as power requirements, dimensions, lamp type, brightness, and supported video formats are listed, along with safety and environmental information. The document also includes wiring diagrams and troubleshooting tips for common issues.
| Brightness | 2000 lm (PT‑U1X86), 1600 lm (PT‑U1X66 / PT‑U1S66) |
|---|---|
| Power Supply | 100–240 V AC, 50/60 Hz |
| Operating Temperature | 0 °C – 40 °C (32 °F – 104 °F) |
| Dimensions (Width) | 81.2 cm (32") |
| Lamp Type | CR2025 |
| RS‑232C Speed | 9600 bps, 8‑N‑1 |
It operates on an input voltage of 100 V to 240 V AC at 50 or 60 Hz.
The PT‑U1X86 provides 2000 lumens, while the PT‑U1X66 and PT‑U1S66 provide 1600 lumens.
