This service manual provides step‑by‑step disassembly and assembly instructions for the Panasonic SB-FS887GK audio system, including safety warnings that the work be performed only by experienced technicians. It covers the removal of front panels, bass and tweeter drivers, wiring terminals, and the base assembly, with diagrams and part numbers for each component.
Technical specifications are listed, such as a 6 Ω impedance, IEC 170 W maximum input power, 85 dB/W output SPL, and a frequency response of 90 Hz–25 kHz. The document also includes wiring connection guidelines, placement recommendations, circuit diagrams, exploded views, and a comprehensive parts list with part numbers and quantities. This manual is written in Chinese.
| Input Power (max) | IEC 170 W |
|---|---|
| Output SPL | 85 dB/W (1 m) |
| Frequency Range | 90 Hz–25 kHz (-16 dB) |
| Dimensions (W×H×D) | 260 mm × 1355 mm × 269 mm |
| Weight | ≈5.23 kg |
The manual states it is intended only for experienced repair technicians and that improper repair may cause serious injury or death.
The system consists of a 2‑channel, 3‑speaker configuration plus an active subwoofer.
