This manual is a setup manual for the XG-PH70X XG-PH70X-N multimedia projector, which mainly introduces the connection, setting and use methods of the projector.
This manual explains how to position the XG-PH70X projector for optimal image quality, including screen distance, lens alignment, and keystone correction avoidance. It also details the optional Sharp lenses and their throw‑distance ratios.
Network setup, RS‑232C/Telnet control, and LAN‑based functions such as lamp‑timer reset and error‑report e‑mail configuration are covered, along with advanced menu options for video‑wall and stack projection.
| Standard Zoom Lens (AN-PH31EZ) focal length | 25.6‑31.3 mm (F1.8‑F2.0) |
|---|---|
| Fixed Wide Lens (AN-PH10EX) focal length | 11.6 mm (F2.5) |
Place the projector perpendicular to the screen with its feet flat and level, and keep the lens centered on the screen.
Use the LAN command for resetting the lamp timer as described in the ‘Resetting the Lamp Timer of the Projector via LAN’ section.
