This document provides the user manual for the HD8943 / HD8944 coffee machine, including installation, startup, settings, and adjustments.
This manual provides step‑by‑step instructions for installing, setting up and operating the Philips HD8943/HD8944 coffee maker. It includes language selection, water‑hardness measurement, Intenza filter installation, and detailed guidance for preparing espresso, cappuccino, latte and other drinks.
Safety precautions, regular cleaning, descaling procedures and troubleshooting tips are also covered to ensure reliable long‑term performance of the machine in a home environment. This manual is written in Chinese.
| Dimensions (L × H × W) | 280 × 370 × 420 mm |
|---|---|
| Weight | 17 kg |
| Water tank capacity | 1.6 L |
| Coffee bean hopper capacity | 350 g |
| Pump pressure | 15 bar |
| Grinder type | Ceramic grinder |
| Coffee grind amount per brew | 7 – 10.5 g |
| Grounds container capacity | ≈15 servings |
| Power‑cord length | 1200 mm |
Press the language button on the control panel, select the desired language, and confirm with the save key.
Insert the supplied hardness test strip into water for 1 second, compare the colour to the chart, then set the corresponding hardness level in the menu.
Remove the filter from the package, soak it upright in cold water, press the sides to release air bubbles, place it in the water‑tank base and confirm with OK.
