AK 1703 ACP Operation and Maintenance Manual introduces how to parameterize TM 1703 ACP system and explains possible errors and available diagnostics.
This manual covers the AK 1703 ACP automation unit, describing safety precautions, hardware components, and the engineering tools required for configuration and testing. It explains how to use the TOOLBOX II software for parameterization, import/export of settings, and remote control functions.
The document also details maintenance activities, including module replacement, hardware diagnostics, firmware updates, and procedures for safely disconnecting power before work. Reference tables list the various modules, power supplies, and bus interfaces used in the system.
| Power Supply Models | PS-5620, PS-5622 |
|---|---|
| Bus Interface Modules | CM-0843, CM-0842 |
| Supported Operating System | Windows 2000 Professional |
| Main Control Unit | CP2010/CPC25 |
| Processing and Communication Module | CP-2017/PCCX25 |
The manual uses the symbols Danger, Warning, Note, and Attention to indicate the level of hazard.
Before any maintenance, the power must be disconnected.
The TOOLBOX II software is used for engineering tasks, parameter setting, and remote control.
The document number is SIC1703-HBAKACPOpMaint-ENG_V2.00.
