Lenovo ThinkCentre M80 Tower is a computer product that uses Intel Core i architecture processor, Intel latest chipset, DDR3 memory, supports SATA 2.0(300 MB/s) architecture, Gigabit Ethernet network, front sound effects and USB 2.0 sockets, supports all ThinkVantage Technologies, and has a three-year warranty.
This leaflet introduces the ThinkCentre M80 upright desktop, highlighting its Intel Core i3 processor, DDR3 memory, and integrated Intel HD graphics. It also outlines the connectivity options, storage capacity, and physical dimensions of the system.
The document lists the three‑year parts and on‑site service warranty, security features such as BIOS passwords and lock slots, and the supported operating system (Windows 7 Professional 32‑bit). It serves as a quick reference for customers and service personnel. This manual is written in Chinese.
| Processor | Intel Core i3-540 (3.06 GHz, 4 MB cache, 1333 MHz FSB) |
|---|---|
| Storage | 320 GB 7200 rpm SATA 2.0 HDD |
| Optical Drive | 16× DVD drive with SATA interface |
| Chipset | Intel H57 |
| Graphics | Intel HD Graphics |
| Network | Gigabit Ethernet |
| Power Supply | 280 W, 110 V/240 V selectable |
| Dimensions | 160 mm × 422 mm × 388 mm (W × D × H) |
The system is supplied with Windows 7 Professional 32‑bit.
The machine supports BIOS passwords, hard‑disk passwords, a lock slot, and configurable boot order.
