The document is a technical manual for RDE.3035, which includes product specifications, dimensions, wiring diagrams, etc.
The Siemens M3035 RDE product data sheet lists the main model variants such as 3035A03, 3036A02, 3035A04 and 3035M01. It includes the product identification, electrical ratings and mechanical dimensions.
Key electrical specifications include a rated voltage of 230 V AC, a voltage operating range of 24 V to 250 V AC, and a maximum current of 5 A. Physical dimensions are given in millimetres, for example a height of 112.34 mm. This manual is written in Chinese.
| Rated Voltage | 230 V AC |
|---|---|
| Voltage Range | 24–250 V AC |
| Height | 112.34 mm |
The rated voltage is 230 V AC.
It operates from 24 V up to 250 V AC.
