AV-21K3 TV user manual, introduces the functions and use methods of the TV, including receiving settings, TV preparation, daily use methods, function use, machine connection, etc.
This manual explains how to prepare and install the Victor AV-21K3 flat television, including antenna connection, channel tuning, and basic operation such as picture and sound adjustments. Safety warnings, power‑supply requirements, and proper handling are highlighted to prevent fire, electric shock, and damage.
Additional sections cover advanced features like digital EE settings, channel editing, connecting external devices (DVD, video deck, game consoles), and troubleshooting common issues. Warranty information and service contacts are provided at the end of the document. This manual is written in Japanese.
| 受信方式 | NTSG |
|---|---|
| 受信チャンネル | VHF 1‑18, UHF 13‑68 |
| 使用電源 | AC100V、50Hz/60Hz |
| 消費電力 | 101W |
| 待機時消費電力 | 0.1W |
| 年間消費電力量 | 91kWh/年 |
| 画面寸法 (幅×高さ×対角) | 40.4 cm × 30.3 cm × 50.6 cm |
| 音声出力 | 5W |
| スピーカーサイズ | 5 cm × 12 cm |
| アンテナ端子 | VHF/UHF:75Ω、F型 |
| 音声出力端子電圧 | 0.5V(rms) ローインピーダンス |
| ヘッドホン端子 | 3.5 mm ステレオミニジャック |
| 最大外形寸法 | 59.6 cm × 46.9 cm × 48.8 cm |
| 質量 | 25.5 kg |
The TV consumes 101 W during operation and 0.1 W in standby.
No, the TV is intended for use in Japan only because of differing broadcast standards and power voltage.
