The Victor MX‑S7WMD is a compact component MD system designed for digital audio playback. The manual covers basic operation such as playing CD, MD, and radio, recording functions, timer settings, and remote‑control usage. Safety instructions, power‑saving features, and recommended placement are detailed to ensure safe and reliable use.
Technical specifications for the built‑in speaker system, power consumption, and supplied accessories are listed, along with warranty and service contact information for Victor products in Japan. This manual is written in Japanese.
| Power supply voltage | AC100V (50Hz/60Hz) |
|---|---|
| Power consumption (standby, eco mode on) | 1.4 W |
| Low‑frequency driver | 14.5 cm cone, 1 unit |
| Mid‑high driver | 3.0 cm balanced‑dome, 1 unit |
| Tweeter | 1.5 cm dome, 1 unit |
| Frequency response | 40 Hz – 20 kHz |
| Maximum SPL | 84.5 dB/W·m |
| Speaker dimensions | 170 mm × 290 mm × 212 mm |
| System dimensions | 555 mm × 290 mm × 335 mm |
| System weight | ≈13.6 kg |
The remote control uses two AA (単3形) dry cells for operation.
In standby with the eco‑mode on, the unit consumes 1.4 W.
