The S200 series brushless servo drives from Danaher Motion drive the application of high-performance servo technology in the lower-end field, with high resolution feedback and high-performance current loop bandwidth, providing smooth motion and fast response, suitable for applications in semiconductor manufacturing, electronic assembly, packaging, as well as medical, wood processing, and general automation.
The S200 series high‑performance servo driver from Danaher Motion provides a compact, fully digital solution for a wide range of automation applications, including semiconductor manufacturing, packaging, medical and woodworking. It features a 24‑bit feedback resolution, 5 kHz current‑loop bandwidth and 800 Hz speed‑loop bandwidth, enabling smooth motion and fast response.
The driver is available in AC (85‑265 VAC) and DC (10‑90 VDC) versions, supports up to 6 A continuous output current (18 A peak), and offers optional SynqNet communication, torque and speed control, and smart feedback devices. A single cable can supply power and feedback, simplifying installation and reducing system cost. This manual is written in Chinese.
| Input voltage (AC) | 85‑265 VAC, 47‑420 Hz, 1 phase |
|---|---|
| Input voltage (DC) | 10‑90 VDC |
| Continuous output current | 1.5 A RMS ~ 6 A RMS |
| Peak output current | 4.5 A RMS ~ 18 A RMS |
| Current‑loop bandwidth | 5 kHz |
| Speed‑loop bandwidth | 800 Hz |
| Feedback resolution | 24 bit |
| Dimensions (AC version) | 1.1 in (28.7 mm) W × 6.0 in (152.4 mm) H |
Yes, a single cable can supply both power and feedback, simplifying wiring and reducing cost.
SynqNet is available as an optional communication card for the S200 driver.
