This document introduces the product overview, technical data and dimensions, motors, mounting elements, lubrication, calculations, technical data, permissible speeds, permissible drive torques, maximum axial loading of mechanical cylinder system, configuration and ordering of Electromechanical Cylinder EMC R310A.
The Electromechanical Cylinder EMC (model R310A 3306) from Bosch Rexroth combines a ball‑screw drive with a piston rod to replace pneumatic or hydraulic cylinders. It offers precise positioning, high thrust capability, and compact construction for a variety of linear motion applications.
The manual covers product overview, technical specifications, mounting methods (motor mount and belt‑side drive), lubrication, calculations for length and load, permissible speeds and torques, and detailed ordering forms. It also includes tables of dimensions, ball‑screw sizes, and maximum axial forces for each size variant.
