This document describes the features of the HT46R23/HT46C23 A/D type eight-bit microcontroller, including operating voltage range, number of input/output ports, programmable timer/counters, memory capacity, A/D converter, PWM output, etc.
The HT46R23 (OTP version) and HT46C23 (masked version) are 8‑bit RISC microcontrollers designed for sensor A/D conversion, motor control, industrial and consumer applications. They provide flexible I/O, programmable timers, built‑in oscillators, watchdog, and low‑power halt/wake functions.
The document includes functional descriptions, pin‑out diagrams, electrical characteristics, timing parameters, register maps and mechanical dimensions for the 24‑pin SKDIP/SOP and 28‑pin SOP packages. This manual is written in Chinese.
| Operating voltage (fSYS = 4 MHz) | 2.2 V ~ 5.5 V |
|---|---|
| Operating voltage (fSYS = 8 MHz) | 3.3 V ~ 5.5 V |
| Maximum bidirectional I/O pins | 23 |
| A/D converter channels | 8 channels, 10‑bit resolution |
| PWM output channels | 2 channels, 8‑bit |
| Program memory (ROM) | 4096 × 15 bits |
| Data memory (RAM) | 192 × 8 bits |
| Operating temperature range | -40 °C ~ 85 °C |
It provides up to 23 bidirectional I/O pins.
The microcontroller includes an 8‑channel, 10‑bit A/D converter.
The required supply voltage is between 2.2 V and 5.5 V.
Program memory is 4096 × 15 bits and data memory is 192 × 8 bits.
