Honeywell SS94B1 series analog Hall effect position sensors have single sink or source current output, enhanced temperature stability, three-pin-in-line pins, laser-corrected thin-film and thick-film resistors, reduced sensitivity changes and temperature compensation.
The SS94B1 series is an analog Hall‑effect position sensor with a three‑pin package and enhanced temperature stability. It offers a supply voltage range of 4.5 V to 12 V and typical operating current of 8 mA at 5 V.
The sensor delivers a typical sensitivity of about 3.12 mV per Gauss with a temperature coefficient of ±0.03 %/°C. Output voltage varies linearly with magnetic field, centered around the mid‑supply voltage, and the device includes specifications for temperature range, output characteristics, and mechanical dimensions. This manual is written in Japanese.
| Supply voltage (VDC) | 4.5 V – 12 V |
|---|---|
| Operating current (typical) at 5 V | 8 mA |
| Maximum current | 4 mA |
| Sensitivity | 3.123 mV/Gauss (typical) |
| Temperature coefficient of sensitivity | ±0.03 %/°C |
The SS94B1 operates from 4.5 V to 12 V supply voltage.
Typical current consumption is 8 mA when powered at 5 V.
The sensor provides a sensitivity of about 3.12 mV per Gauss.
Sensitivity changes by approximately ±0.03 % per degree Celsius.
