This technical note provides recommended pressure tubing for Honeywell 20PC SMT pressure sensors.
The manual introduces the Honeywell 20PC SMT surface‑mount pressure sensor, describing its design for accurate pressure measurement and its suitability for various industrial applications. It includes contact information for Honeywell sales and support teams.
Key details cover the available package sizes (1/8, 1/16, 0.032 inch), pressure ranges, operating temperature, and typical pressure units. The document also lists the sensor's maximum pressure rating and environmental limits. This manual is written in Chinese.
| Package size | 1/8, 1/16, 0.032 inch |
|---|---|
| Pressure measurement units | 100, 500, 1000 |
The sensor is offered in 1/8, 1/16, and 0.032 inch packages.
