The TDS1000B and TDS2000B series oscilloscopes are high-performance, easy-to-use digital storage oscilloscopes that offer 200 MHz bandwidth and 2 GS/s maximum sample rate. These oscilloscopes feature an intuitive user interface, multiple functions such as removable data storage, seamless PC connectivity, and direct printing.
The TDS1000B and TDS2000B series are digital storage oscilloscopes offering bandwidths of 40 MHz to 200 MHz, up to 2 GS/s real‑time sampling, and 2‑ or 4‑channel configurations. They feature color or monochrome LCD displays, built‑in FFT, advanced triggering, and USB connectivity for data storage and PC communication.
This manual describes the instrument’s front‑panel functions, automatic setup menu, trigger system, measurement capabilities, safety and environmental limits, physical dimensions, and ordering information. It also includes details on accessories, warranty, and software integration with OpenChoice® and NI SignalExpress®. This manual is written in Chinese.
| Bandwidth | 40 MHz, 60 MHz, 100 MHz, 200 MHz |
|---|---|
| Maximum real‑time sample rate | 2 GS/s |
| Number of channels | 2 or 4 |
| Display type | Color or monochrome LCD |
| USB ports | 2 × USB 2.0 (host and device) |
| Vertical sensitivity | 2 mV – 5 V/div |
| Maximum input voltage | 300 V RMS CAT II |
The series offers bandwidths of 40 MHz, 60 MHz, 100 MHz, and 200 MHz.
Models are available with either 2 channels or 4 channels.
Each model includes two USB 2.0 ports – a host port for flash drives and a device port for PC connection.
