This document is the user manual for the Colorful C.A770 motherboard. It mainly introduces the hardware installation, driver installation and BIOS settings of the motherboard.
This manual provides step‑by‑step instructions for installing the Colorful C.A770 and C.A770T motherboards, including hardware assembly, driver installation, and BIOS configuration. It also lists the supported CPUs, memory types, and peripheral interfaces.
The document includes detailed BIOS update procedures, safety notices, and a parts checklist. It is intended for end‑users and system builders who need to set up or maintain these motherboards. This manual is written in Chinese.
| Chipset | AMD 770+SB700 |
|---|---|
| Memory Type | DDR2 533/667/800, dual‑channel, up to 800 MHz |
| DIMM Slots | 4 × 240‑pin DDR2 slots |
| SATA Ports | 6 × SATA III ports |
| eSATA Port | 1 × eSATA (C.A770 only) |
| Network Interface | Integrated Gigabit Ethernet (10/100/1000 Mbps) |
| Audio | 8‑channel audio codec (C.A770) / 6‑channel (C.A770T) |
It provides six SATA ports, and the C.A770 version also includes one eSATA port.
The motherboard uses the AMD 770+SB700 chipset.
