This manual introduces the hardware installation, driver installation and BIOS setup methods for C.D55K D3 V20 and C.D45T D3 V20 motherboards.
This manual provides an overview of the Colorful C.D55K D3 V20 and C.D45T D3 V20 motherboards, including product features, hardware installation steps, driver installation instructions, and detailed BIOS configuration options. It also contains safety information, regulatory compliance notes, and contact details for technical support.
The document is organized into chapters: Introduction, Hardware Installation, Driver Installation, BIOS Settings (with advanced and security options), and an Appendix with additional resources such as BIOS flashing procedures and troubleshooting codes. It includes diagrams of the board layout and connector pin‑outs. This manual is written in Chinese.
| Chipset | Intel D525+NM10 / Intel D425+NM10 |
|---|---|
| CPU | Integrated Atom D525/D425 processor |
| Memory | 2 DDR3 slots, DDR3‑800 |
| Expansion Slots | 1 PCI‑Express x16, 1 PCI‑Express x1, 1 PCI |
| SATA Ports | 2 SATA‑II (3.0 Gb/s) ports |
| Audio | 6‑channel high‑definition audio controller |
| Network | Gigabit Ethernet (C.D45T model uses 10/100) |
