The Polycom HDX 7000 series is a high-quality and user-friendly solution for high-definition video conferencing. It is ideal for remote education, remote healthcare, enterprise communication, and on-demand collaboration. The series features high-definition video, high-definition audio, and high-definition content sharing.
The HDX7000 series is a high‑definition video‑conferencing solution designed for ordinary meeting rooms. It offers flexible installation options, built‑in MCU and content‑sharing capabilities, and advanced audio technologies such as HDVoice™ and StereoSurround™.
Key technical specifications include 720p video at 1280×720 resolution, multiple audio codecs, up to four‑point MCU for multi‑point calls, various network interfaces, and robust power and environmental ratings suitable for typical office environments. This manual is written in Chinese.
| Video resolution | 1280×720 (720p) |
|---|---|
| Audio bandwidth (Siren22) | 14 kHz |
| Network ports | 2×10/100 Mbps RJ45 |
| Power consumption (115 V) | 189 VA @ 115 V @ 60 Hz @ 0.67 PF |
| Operating temperature | 0 °C to 40 °C |
| Storage temperature | -40 °C to 70 °C |
| Maximum altitude | 10 000 ft (≈3000 m) |
| Physical dimensions (HDX8004 host) | 352 mm (H) × 129 mm (W) × 279 mm (D) |
| Built‑in MCU capacity | Up to 4‑point MCU |
It supports a 1280×720 (720p) resolution for natural, smooth HD video.
The optional built‑in MCU can handle up to four points for multi‑point conferencing.
The system operates between 0 °C and 40 °C.
