The Polycom HDX 7000TM series provides high-quality and highly available HD conferencing solutions for mainstream conferencing TV application environments. The series features an intuitive interface, flexible configuration, and built-in MCU and content sharing capabilities. It incorporates Polycom's HD audio technology and stereo surround sound technology, enabling HD file sharing and multimedia content display. Choosing Polycom's conferencing solutions allows for simple and efficient real-time communication and collaboration.
The HDX 7000TM series provides a high‑quality, highly available HD video‑conferencing solution for ordinary meeting rooms, supporting remote education, tele‑medicine, enterprise communication and on‑demand collaboration. It features intuitive interfaces, flexible wall‑mount or free‑standing installation, built‑in MCU, and People+Content sharing for seamless document and media exchange.
Technical specifications include 720p/30 fps video, up to 22 kHz audio bandwidth with Polycom Siren™ and StereoSurround™ technologies, a 12× optical‑zoom EagleEye camera, multiple network interfaces (RJ45, ISDN, serial), and robust power and environmental ratings suitable for commercial deployment. This manual is written in Chinese.
| Maximum video resolution | 720p, 30 fps |
|---|---|
| Audio bandwidth (Siren 22) | 22 kHz |
| Power consumption (115 V) | 189 VA @115 V @60 Hz @0.67 PF |
| Operating temperature | 0 °C to 40 °C |
| Storage temperature | -40 °C to 70 °C |
| Network ports | 2 × 10/100 Mbps RJ45 |
| Camera optical zoom | 12× optical zoom |
It supports up to 720p resolution at 30 fps.
The optional built‑in MCU can support up to four points.
Polycom Siren™22 and StereoSurround™ HD audio technologies provide high‑fidelity sound.
The system operates from 0 °C up to 40 °C.
