The C-12 MX01 is a SL™ Crimp Housing 70066 Single Row Version G with a positive latch from Jameco with 2.54mm (.100 inch) spacing. It features reinforced ribs on the front and back to prevent wires from getting caught under the latch during harness manufacturing and storage. When unmating the connector from a header, the front ribs can prevent contact damage and the housing cannot be twisted off pins.
The 70066 SL Crimp Housing is a single‑row, 2.54 mm (0.100 in) pitch connector with a positive latch that secures the housing to a locking crown. It is designed for high‑density signal applications and can be stacked end‑to‑end for modular wiring solutions.
Key features include a black glass‑filled polyester housing (UL 94V‑0), operating temperature from –40 °C to +105 °C, a voltage rating of 250 V, and various current ratings per AWG. Electrical performance specifications such as 30 mΩ maximum contact resistance, 1000 MΩ minimum insulation resistance, and 1500 VAC dielectric withstand are also provided.
| Pitch | 0.100 in (2.54 mm) |
|---|---|
| Housing Material | Black Glass Filled Polyester, UL 94V‑0 |
| Operating Temperature | -40 °C to +105 °C |
| Voltage Rating | 250 V |
| Current Rating (28 AWG) | 1.2 A |
| Maximum Contact Resistance | 30 mΩ |
| Minimum Insulation Resistance | 1000 MΩ |
| Dielectric Withstand Voltage | 1500 VAC (no breakdown) |
| Maximum Mating Pin Height | 0.320 in (8.13 mm) |
| UL File Number | E29179 |
| CSA File Number | LR19980 |
The pitch is 0.100 in (2.54 mm).
It operates from –40 °C to +105 °C.
It is UL listed under file number E29179 and CSA listed under file number LR19980.
The maximum contact resistance is 30 mΩ.
