The MX01 C-9 C series is a single‑row, stackable linear connector system designed for high‑density signal applications. It supports 2 to 25 circuits and can be used with both wire‑to‑board and wire‑to‑wire configurations.
Key characteristics include a .100" (2.54 mm) pitch, black glass‑filled polyester housing (UL 94V‑0), gold and tin/lead plating, an operating temperature range of –40 °C to +105 °C, a voltage rating of 250 V, and current ratings ranging from 1.2 A (28 AWG) to 3.0 A (24 AWG). The specification also provides detailed test results for electrical, mechanical, and environmental performance.
| Pitch | .100" (2.54 mm) |
|---|---|
| Number of Circuits | 2 to 25 |
| Operating Temperature | -40 °C to +105 °C |
| Voltage Rating | 250 V |
| Current Rating (24 AWG) | 3.0 A |
| Housing Material | Black Glass Filled Polyester, UL 94V‑0 |
| Plating | Gold and tin/lead |
| Insulation Resistance | Minimum 1000 MΩ |
The connector has a .100" (2.54 mm) centerline spacing.
It can accommodate between 2 and 25 circuits.
The connector is rated for –40 °C to +105 °C.
The maximum voltage rating is 250 V.
