SIMATIC IPC427C is a powerful embedded industrial PC with a fanless design that can be used in DIN rail mounting, wall mounting or upright mounting. It has long-term availability and is the ideal choice for implementing high-speed MSR, HMI and communication tasks between neighboring machines in tight spaces.
The SIMATIC IPC427C is a compact, fan‑less embedded industrial PC designed for DIN‑rail, wall‑mount or vertical installation. It offers high reliability for high‑speed MSR, HMI and inter‑machine communication tasks in confined spaces.
The manual details the processor options, memory configurations, graphics controller, supported operating systems, power supply features, interfaces, monitoring functions, environmental limits, EMC compliance, and physical dimensions of the unit.
| Processor | Intel Core2 Duo SU9300 (2 × 1.2 GHz) |
|---|---|
| Memory | 512 MB DDR3 SDRAM (optional 1 GB, 2 GB or 4 GB) |
| Graphics | Intel GMAX4500 controller, up to 512 MB dynamic video memory |
| Storage | 32 GB SSD (optional) with CF card backup |
| Ethernet | 2 × 10/100/1000 Mbit/s RJ45 with bonding |
| Dimensions | 262 mm × 134 mm × 47 mm (W × H × D) |
| Weight | ≈ 2 kg |
The IPC427C can be mounted on a DIN rail, wall‑mounted, or installed vertically.
