This document contains notes on installing and connecting the in-car CD player, including but not limited to fire, electric shock, vehicle performance, disassembly and modification.
The manual begins with important safety warnings, explaining that failure to follow the instructions can lead to fire, electric shock, or vehicle damage. It stresses the need to read the guide thoroughly and keep it accessible for future reference.
The guide then details the installation process: mounting the unit, connecting power, antenna, and speaker cables, selecting appropriate fuses, and verifying all vehicle electrical systems work correctly after installation. It also lists optional accessories and provides wiring diagrams for various car models. This manual is written in Japanese.
| Power supply voltage | DC12V (negative‑earth) |
|---|---|
| Maximum allowable current (power antenna) | 0.9 A |
| Maximum allowable current (other connections) | 0.1 A |
It requires a DC12 V negative‑earth power source designed for car installations.
No. Installing the unit in a 24 V system can cause fire or damage.
