This document describes the features and characteristics of the KDC series CD receivers (including KDC-4023, KDC-3023, KDC-2023, KDC-1023, and KDC-1023S).
This manual covers safety precautions, wiring requirements, and installation steps for the Kenwood KDC CD changer series. It explains how to connect the unit, secure the panel, and avoid short‑circuit hazards.
The guide details basic operation, source selection, CD handling, speaker configuration, panel lock functions, and troubleshooting codes. Technical specifications such as frequency ranges, power supply, dimensions and weight are listed at the end of the document.
| Installation dimensions (H×W×D) | 182 mm × 53 mm × 157 mm |
|---|---|
| Weight | 3.1 lb (1.4 kg) |
| Working voltage | 14.4 V |
| Laser diode wavelength | 780 nm |
| Total harmonic distortion (THD) | ≤ 1 % |
Press the reset button on the unit; if the problem persists, contact a Kenwood service dealer.
Use vehicle‑grade wire of 0.75 mm² (AWG 18) or larger to prevent short‑circuit hazards.
Insert the CD horizontally into the slot and pull it out horizontally when removing.
Yes, the front panel can be detached and stored in its dedicated box to act as an anti‑theft measure.
