The StoreJet 2.5 is a portable USB 2.0 external hard drive offering high‑speed data transfer and optional 2.5‑inch SATA hard‑disk upgrades. It is designed for easy backup and file management across Windows, Mac and Linux computers.
This manual covers product features, safety guidelines, power requirements, installation of the hard‑disk module, formatting, troubleshooting, warranty terms and detailed technical specifications. It also includes step‑by‑step instructions for installing the provided software on various operating systems. This manual is written in Chinese.
| Dimensions (L×W×H) | 129 mm × 79.9 mm × 13 mm |
|---|---|
| Weight | 186 g (including hard disk) |
| Storage Media | 2.5‑inch SATA hard disk |
| Maximum Transfer Rate | 480 Mbits/s |
| Operating Temperature | 5 °C to 55 °C |
| Certifications | CE, FCC, BSMI |
Connect the device to a Windows 2000, XP or Vista computer and run the installer provided on the included CD or download it from the Transcend website.
The drive draws power from the computer’s USB port; if the port cannot supply enough current, a USB Y‑cable can be used to provide additional power.
The device supports up to 480 Mbits per second, the full speed of USB 2.0.
It can be used in environments from 5 °C up to 55 °C.
