This manual introduces the features and characteristics of the MS612ST/MX613ST digital projector, including safety instructions, projector positioning, connections, operation, maintenance and troubleshooting.
This manual introduces the BenQ MS612ST and MX613ST digital projectors, outlining key features such as network management, USB inputs, 3D capability, and built‑in speakers. It includes a complete item list, front‑panel diagram, and detailed descriptions of control buttons and functions.
The guide covers safe installation, connection of video sources, menu navigation, image adjustment, remote operation, and troubleshooting. Maintenance procedures, lamp information, and full technical specifications are provided, along with warranty and regulatory statements. This manual is written in Chinese.
| Optical resolution (MS612ST) | 800 x 600 SVGA |
|---|---|
| Optical resolution (MX613ST) | 1024 x 768 XGA |
| Lamp power (MS612ST) | 190 W |
| Lamp power (MX613ST) | 210 W |
| Maximum power consumption (MS612ST) | 310 W |
| Maximum power consumption (MX613ST) | 336 W |
| Weight | 2.8 kg (6.2 lb) |
| Dimensions (W×H×D) | 311.81 mm × 104.07 mm × 244.11 mm |
| Input voltage range | AC 100–240 V, 3.8 A, 50–60 Hz |
| Operating temperature (sea level) | 0 °C–40 °C |
| RS‑232 control port | 9‑pin |
| HDMI input | HDMI V1.3 x 1 |
The projector works on AC 100 V to 240 V, 3.8 A, 50–60 Hz.
Wait about 45 minutes after the lamp is turned off to allow the projector to cool before replacement.
Yes, it can operate up to 3000 m (10 000 ft) altitude when the high‑altitude mode is enabled.
Open the lens shutter (if present) or remove the lens cap before handling the lamp.
