This document describes the features and characteristics of the SIMATIC distributed I/O system ET 200S, including terminal modules, power modules, digital electronic modules, analog electronic modules, etc.
This manual covers the ET200S distributed I/O system, describing its terminal, power, digital, and analog modules, as well as auxiliary components such as the 4 IQ‑SENSE and potential distributor modules. Safety technical hints and qualified‑person requirements are presented at the beginning of the document.
Detailed module data sheets include dimensions, electrical ratings, wiring diagrams, and configuration parameters, enabling qualified professionals to install, commission, and maintain the system safely and correctly. This manual is written in Chinese.
| TM-P15x23-A1 weight | ≈65 g |
|---|---|
| Maximum AUX1 bus voltage | 230 VAC |
| Power module voltage range | 24 VDC – 48 VDC (and 24‑230 VAC for certain modules) |
The symbols show danger levels: “危险” means possible death or serious injury, “警告” means possible death or serious injury, “小心” (with triangle) means possible minor injury, and “小心” (without triangle) means possible property damage.
The AUX1 bus can handle up to 230 VAC.
