The Barco SIM5W is a WUXGA (1920 × 1200) single‑chip DLP projector designed for multi‑channel applications. It features Barco’s proprietary edge‑blending, constant light output, constant contrast dimming, and color‑matching technologies to deliver seamless, high‑quality images across multiple screens, including curved and non‑planar surfaces.
The leaflet lists the technical specifications: 2 000:1 full‑field contrast ratio, dual 250 W UHP lamps with a 3 000 h standard life, 14.8 kg weight, 415 × 487 × 195 mm dimensions, and a range of video and data inputs (DVI‑D, VGA, HDMI, component, S‑Video, DVD‑D). Communication ports include RS‑232, RJ9, and RJ45 Ethernet. Safety certifications (ETL, FCC, CE) and power requirements (100‑240 V, 700 W max) are also provided. This manual is written in Japanese.
| Contrast Ratio | 2,000:1 full‑field |
|---|---|
| Resolution | WUXGA (1920 × 1200) |
| Lamp Power | 250 W × 2 UHP |
| Lamp Life (standard) | 3,000 h |
| Weight | 14.8 kg (body only) |
| Dimensions (W × H × D) | 415 × 487 × 195 mm |
| Maximum Power Consumption | 700 W |
| Power Input | AC 100‑240 V, 50/60 Hz |
It has a WUXGA resolution of 1920 × 1200 pixels.
It includes RS‑232 (RJ9) and RJ45 Ethernet ports.
