This document is a detailed introduction to the KX-FP706CN-W / KX-FP706CN-B high-end plain paper fax machine produced by Panasonic Corporation. It introduces the product's safety precautions, warnings, technical specifications, functions, technical explanations, and the location of controls and components.
This service manual is intended for experienced technicians who service the Panasonic KX‑FP706CN fax machine. It includes safety warnings, detailed disassembly instructions, wiring diagrams, and part replacement lists.
The document also contains technical specifications such as dimensions, weight, power consumption, and transmission speed, as well as guidance on using the correct lead‑free solder (PbF) for repairs. This manual is written in Chinese.
| Maximum width | 216 mm |
|---|---|
| Maximum length | 600 mm |
| Weight (including accessories) | ≈ 4 kg |
| Weight (machine only) | ≈ 3.5 kg |
The power cord must be unplugged from the AC source to prevent electric shock.
