The SIMATIC Panel PC is not only the ideal solution for machine-level HMI systems, but also a powerful industrial PC for other tasks such as open-loop control, closed-loop control, data processing and motion control.
This manual describes the SIMATIC PC family (models 477, 577, 677, 877) and provides the information needed to install, configure, and operate the hardware. It includes system requirements, hardware layout, BIOS management, and diagnostic tools.
Key sections cover hardware specifications, supported operating systems, connectivity options (PCI, ISA, PROFIBUS/MPI, USB), and software tools such as WinCC flexible and DiagMonitor. Installation steps, wiring diagrams, and maintenance procedures are also included.
| Memory (RAM) | 256 MB – 2 GB |
|---|---|
| Hard Disk | Minimum 40 GB |
| PCI Slots | 2 × PCI, 2 × PCI‑ISA |
| Power Supply | 24 VDC, 230 VAC |
The system provides two PCI slots and two PCI‑ISA slots.
The unit can be powered from 24 VDC or from 230 VAC mains.
