JPS IRIS-IMAC Driver User Manual

This document is the user manual of JpS IRIS-IMAC DRIVER USER MANUAL, introducing the characteristics and features of the product

Brand: JPS
Category: Motor
Document type: User Manual
Language: English
Pages: 60
File format: PDF
File size: 1.3 MB
Published: 11 December, 2011
Updated: 30 September, 2023
MD5 checksum: 5FE18EE6194BB63E08C327AA10CAA87B
PDF: JPS IRIS-IMAC Driver User Manual PDF

About this manual

This manual covers safety precautions, qualified personnel requirements, and handling instructions for the IRIS‑IMAC driver, including warnings about high voltage and capacitor discharge. It also explains the meaning of name‑plate markings and the different control‑panel options.

The document details the installation process, wiring diagrams, digital control‑panel functions, parameter configuration, alarm messages, maintenance procedures, and certification information. Technical specifications such as input voltage, output current, power rating, and frequency range are listed for various model variants.

What's inside

Safety Precautions
Description of IRIS Driver
Installation and Wiring
Digital Control Panel
Parameter Settings
Maintenance and Alarms
Certificates

Specifications

Input voltage	220 V / 50‑60 Hz
Model designation	2R5‑IMAC‑A
Output current (various models)	3.5 A‑90 A
Output horsepower (various models)	1 HP‑30 HP

Frequently asked questions

How long must I wait before opening the inverter cover after power is removed?

Wait at least five (5) minutes after removing AC power to allow the DC‑link capacitors to discharge.

What is the rated input voltage for the IRIS‑IMAC driver?

The driver is rated for 220 V AC at 50‑60 Hz.

What is the exact model number shown on the name‑plate?

The name‑plate lists the model as 2R5‑IMAC‑A.

Download PDF (1.3 MB)
