TC74VCX162823FT is a low-voltage CMOS 18-bit D-type flip-flop produced by Toshiba. It features low power consumption, high speed, input and output ports can tolerate 3.6 V voltage, and is suitable for 1.8 V, 2.5 V, 3.3 V systems. It is more convenient to use in dual-power systems.
The TC74VCX162823FT is a low‑voltage CMOS 18‑bit D‑type flip‑flop designed for 1.8 V‑8.6 V supply operation. All inputs and outputs tolerate up to 3.6 V, making it suitable for dual‑supply systems and bus‑line interfacing.
Key electrical characteristics include a typical output current of up to 12 mA, 26 Ω series resistance on each output, and operation across a wide temperature range (‑40 °C to 85 °C). The device is offered in a TSSOP56 package and includes built‑in protection diodes for input over‑voltage and output high‑impedance control. This manual is written in Japanese.
| Supply voltage (VCC) | 1.8 V – 8.6 V |
|---|---|
| Output series resistance | 26 Ω |
| Package | TSSOP (Thin Shrink Small Outline Package) |
| I/O voltage tolerance | 3.6 V tolerant |
The device operates from 1.8 V up to 8.6 V.
It is supplied in a TSSOP56 (Thin Shrink Small Outline Package).
Yes, all inputs and outputs tolerate up to 3.6 V regardless of the supply voltage.
