This document is about the introduction of different models of MC9S08DZ16 and MC9S08DZ32 series microcontrollers. These microcontrollers have different packages and operating temperature ranges, and they have different storage capacities and operating voltages. They are suitable for various application fields.
The document provides an overview of Freescale's HCS08 family of 8‑bit microcontrollers, covering several sub‑series such as S08DYV, S08DN and S08SH. Each part number is listed with its package type, flash memory, RAM, operating temperature and electrical characteristics.
Detailed tables give the device codes (e.g., MC9S08DZ16CLC), package dimensions (LQFP 32, LQFP 48, PDIP 20, etc.), memory capacities (up to 62 KB flash, 4 KB RAM) and supported peripherals such as CAN, LIN, ADC and comparators. The data is intended for designers selecting the appropriate MCU for automotive, industrial and consumer applications. This manual is written in Chinese.
| CPU Architecture | 8‑bit |
|---|---|
| CAN and LIN Controllers | Included in S08DYV series |
| Operating Temperature | -40 °C to 125 °C |
| Package Types | LQFP 32, LQFP 48, LQFP 64, PDIP 20, TSSOP 16, etc. |
The HCS08 devices are offered in LQFP 32, LQFP 48, LQFP 64, PDIP 20, TSSOP 16, TSSOP 20 and other package styles.
The S08DYV series of HCS08 microcontrollers includes built‑in CAN and LIN controller functions.
The devices are rated for operation up to 125 °C.
