Featured 飞思卡半导体 manuals

Freescale MC34674 Datasheet

Datasheet 2 pages · 590 KB · ZH

The MC34674 is a fully automatic, single‑input battery charger IC designed for portable devices powered by lithium‑ion or lithium‑polymer cells. It offers flexible, factory‑programmable parameters such as pin functions, thermistor options, and charging settings, allowing customization for various applications like handheld chargers, travel adapters, and digital cameras.

Key features include a compact 2 mm × 3 mm × 0.65 mm UDFN thermal‑enhanced package, up to 1.05 A programmable charge current, input voltage up to 28 V with over‑voltage protection, and no need for external FETs, diodes, or current‑sense resistors. The device provides precise voltage regulation (±0.4% from –20 °C to +70 °C) and programmable functions such as trickle charge, EOC detection, and indicator pin configuration. This manual is written in Chinese.

Covers: Overview · Features · Specifications · Package · Evaluation Board · Selection Guide

Freescale HCS08 8-bit Microcontroller Datasheet

Datasheet 1 pages · 190 KB · ZH

The document provides an overview of Freescale's HCS08 family of 8‑bit microcontrollers, covering several sub‑series such as S08DYV, S08DN and S08SH. Each part number is listed with its package type, flash memory, RAM, operating temperature and electrical characteristics.

Detailed tables give the device codes (e.g., MC9S08DZ16CLC), package dimensions (LQFP 32, LQFP 48, PDIP 20, etc.), memory capacities (up to 62 KB flash, 4 KB RAM) and supported peripherals such as CAN, LIN, ADC and comparators. The data is intended for designers selecting the appropriate MCU for automotive, industrial and consumer applications. This manual is written in Chinese.

Covers: Product Overview · Series and Sub‑Series · Package Types · Memory Capacities · Operating Temperature Range · Peripheral Features

Freescale MPC8315E Communication CPU Integration Manual

User Manual 2 pages · 420 KB · ZH

The MPC8315E series is a communication‑oriented CPU built around Freescale's e300 core, offering up to 400 MHz processing speed, 16 KB L1 cache, and a range of high‑speed interfaces such as PCI Express, SATA, USB 2.0, and Gigabit Ethernet. It targets SOHO and embedded applications that require robust networking, storage, and multimedia capabilities.

Key features include dual‑channel DMA, hardware security accelerators for AES, DES, 3DES, MD5 and SHA‑1, and support for DDR1/DDR2 memory up to 266 MHz. The device is offered in a TEPBGAII package and includes optional security modules and development tools. This manual is written in Chinese.

Covers: Overview · Core Architecture · Features · Security · Package

Freescale MCF51JM128 32-bit ColdFire USB Microcontroller Manual

Datasheet 2 pages · 591 KB · ZH

The MCF51JM128 is a 32‑bit V1 ColdFire® microcontroller featuring a USB On‑The‑Go (OTG) interface, CAN controller, 12‑channel 12‑bit ADC, and extensive peripheral options. It offers up to 128 KB flash, 16 KB SRAM, and operates from 2.7 V to 5.5 V across –40 °C to +105 °C.

The device includes security modules such as a Cryptographic Acceleration Unit (CAU) supporting DES, 3DES, AES, MD5, SHA‑1, and a Random Number Generator Accelerator (RNGA). Development is supported by CodeWarrior tools, USB‑LITE protocol stack, and BDM debugging interfaces. This manual is written in Chinese.

Covers: Features and Advantages · Peripheral Devices · Hardware Development Support · Package Options · Target Applications · Overview

Latest 飞思卡半导体 manuals

• Freescale MC34674 Datasheet

  Datasheet 2 pages · 590 KB · ZH

  The Freescale MC34674 datasheet describes a single‑input, fully automatic lithium‑ion battery charger IC with up to 1.05 A charge current, 28 V input rating…

• Freescale HCS08 8-bit Microcontroller Datasheet

  Datasheet 1 pages · 190 KB · ZH

  This datasheet lists specifications for Freescale HCS08 8‑bit microcontrollers, including part numbers, packages, memory sizes and temperature ranges.

• Freescale MPC8315E Communication CPU Integration Manual

  User Manual 2 pages · 420 KB · ZH

  The Freescale MPC8315E integration communication CPU manual provides an overview of the e300 core, supported interfaces, memory options, and security features.

• Freescale MCF51JM128 32-bit ColdFire USB Microcontroller Manual

  Datasheet 2 pages · 591 KB · ZH

  Technical overview and specifications for the Freescale MCF51JM128 32‑bit ColdFire USB microcontroller.

• FSC Semiconductor LC8635XX CPU User Manual

  User Manual 36 pages · 285 KB · ZH

  Technical manual for the LC8635XX CPU covering features, ports, keys and configuration options.

• Freescale MQX Real-Time Operating System User Manual

  User Manual 138 pages · 1.4 MB · ZH

  Freescale MQX user manual covering OS overview, usage, configuration, and FAQs for MC9RS08KA1/KA2 devices.

• Freescale K20PBZHS Microcontroller Product Overview

  Product Leaflet 44 pages · 1.6 MB · ZH

  This Freescale product overview details the features, specifications, and options of the K20PBZHS series microcontrollers.

• Freescale K60 Microcontroller Product Overview

  Product Leaflet 38 pages · 1.5 MB · ZH

  The Freescale K60 microcontroller product overview details the series' features, specifications, modules, power modes, and development tools.

• Freescale K40 Series Product Overview

  Product Leaflet 36 pages · 1.4 MB · ZH

  This Freescale K40 Series product overview describes the microcontroller family’s core, memory options, peripherals, power modes and development tools.

• Freescale K30 Series Microcontroller Product Overview

  Datasheet 34 pages · 1.4 MB · ZH

  Product overview of Freescale K30 series microcontrollers, covering features, specifications, power modes and development tools.
