This manual is the user manual for the Epson EMP-83H/822H/X5/S5 projector, which introduces the functions, operating methods and safety precautions of the projector.
This manual explains how to install, configure, and operate the Epson EMP‑83H, EMP‑822H, EMP‑X5 and EMP‑S5 projectors. It covers component identification, control panel and remote functions, useful features such as A/V mute, password protection, and operation lock, as well as safety guidelines.
Detailed sections describe connection options for video, audio, LAN and USB, maintenance procedures like lamp and filter replacement, and a full specifications table. The appendix includes command references, network settings, and troubleshooting help. This manual is written in Chinese.
| Dimensions (W×H×D) | 327 mm × 92 mm × 245 mm |
|---|---|
| Resolution | XGA (1024 × 768) |
| Lamp Power | 170 W UHE lamp (ELPLP42 / ELPLP41) |
| Weight | ≈ 2.9 kg |
| Power Supply | 100‑240 V AC ±10 %, 50/60 Hz |
| Standby Power (network off) | 4.1 W |
| Operating Temperature | 5 °C – 35 °C (no condensation) |
Press the [Aspect] button on the remote or control panel; each press cycles the aspect ratio.
Set a password in the configuration menu and enable the operation lock to restrict panel button functions.
