This document is the user manual of LW-8154LR+(I) wireless bridge, which introduces the features and characteristics of the product, typical applications, system requirements, hardware installation and other contents
The LW-8154LR+ (I) is an outdoor 5.8 GHz wireless bridge that complies with IEEE 802.11a and uses OFDM technology. It features a built‑in 23 dBi directional panel antenna, PoE power, waterproof housing and a web‑based management interface.
The manual provides product overview, hardware installation steps, initial setup, web configuration procedures, and detailed technical specifications such as supported data rates, power requirements, and environmental limits. This manual is written in Chinese.
| Operating frequency | 5.8 GHz ISM band |
|---|---|
| Antenna gain | 23 dBi panel antenna |
| Maximum data rate | 54 Mbps |
| Power supply | 100‑240 VAC, 50/60 Hz, 800 mA; 48 V DC, 750 mA |
| Ethernet interface | 10/100 Base‑TX RJ‑45 (1 port) |
| Operating temperature | -10 °C to 60 °C |
| Storage temperature | -20 °C to 80 °C |
| RF output power | 40 dBm |
| Receiver sensitivity | -87 dBm @ 54 Mbps |
The default IP address is http://192.168.0.228.
The default username is admin and the default password is password.
A 48 V, 750 mA power module is required to supply the bridge.
Yes, the bridge supports Super AG PoE power supply.
