This manual provides installation, configuration, and usage instructions for the Lenovo LSC-710 54M USB Wireless Adapter.
The guide walks you through installing the LSC-710 USB wireless adapter, connecting the antenna, and using the Lenovo utility software to configure network settings. It explains the LED indicators, including the LNK LED that shows link status, and details how to select SSID, mode (Infrastructure or Ad‑Hoc), and channel.
Security options such as WEP and WPA‑PSK are described, along with supported data rates and the Turbo mode for higher throughput. The manual also lists the operating temperature range, power consumption, and physical dimensions of the device.
| Frequency band | 2412 ~ 2484 MHz (ISM band) |
|---|---|
| Maximum data rate | 54 Mbps |
| Typical current consumption | 230 mA |
| Dimensions (W × H × D) | 77 × 26 × 12 mm |
| Relative humidity | 10 % ~ 95 % RH |
The LNK LED lights to show that the adapter has an active wireless link.
The utility works with Windows 98 SE, Windows ME, Windows 2000, and Windows XP.
Both WEP and WPA‑PSK encryption are supported.
It supports 802.11g and 802.11b, with optional Turbo mode for higher speeds.
