This manual describes the basic use of the BenQ PQ/SQ Series Color LCD TV. The document includes safety precautions, product overview, connecting audio and video inputs, remote control function introduction, adjusting screen ratio, on-screen display menu, watching digital photos and other contents.
This manual provides safety guidelines, cleaning and maintenance tips, and a detailed overview of the BenQ PQ/SQ series color LCD televisions. It explains the front and rear panels, control buttons, remote‑control functions, and how to connect audio/video sources such as HDMI, D‑Sub, component and S‑Video.
The document also covers picture‑adjustment menus, PC‑connection settings, supported resolutions, and a troubleshooting section for common issues like power problems, no picture or sound, and remote‑control failures. Reference information includes specifications, dimensions, and regulatory details. This manual is written in Chinese.
| Weight with base | 19.6–30.6 kg |
|---|---|
| Weight without base | 18.3–28 kg |
| Dimensions with base (W×H×D) | 1016.1 × 749.2 × 290 mm – 1262.8 × 895.2 × 400 mm |
| Screen size | 42", 46", 52" |
| Aspect ratio | 16:9 |
| Native resolution | 1920 × 1080 |
| Brightness (typical) | 500 cd/m² |
| Contrast (typical) | 5000:1 |
| Viewing angle | 89° horizontal / 89° vertical |
| Response time | 5.5–6.5 ms |
| Built‑in speakers | 10 W × 2, 112 Hz ~ 20 kHz |
| HDMI/DVI inputs | 3 |
| PC D‑Sub input | 1 |
| Maximum power consumption | 205 W – 265 W |
| Operating temperature | 0 °C ~ 40 °C |
| Storage temperature | -20 °C ~ 60 °C |
| Supported video formats | NTSC / PAL / SECAM |
| Remote control model | RC‑H081 |
Check that the power outlet’s switch is on, ensure the power plug is firmly inserted into the TV and the wall socket, and verify the outlet supplies power with another device.
Use the “Adjust Picture Ratio” menu option to change the aspect setting so the image fills the whole screen and eliminates black bars.
The TV supports HDMI input resolutions up to 1080p60, including 480i/p, 576i/p, 720p, and 1080i/p at both 50 Hz and 60 Hz.
