Stanford Research Systems DS360 Error Codes: List of 3 Codes and Their Meaning

This is the list of error codes the Stanford Research Systems manual gives for the DS360 DS360 Ultra Low Distortion Function Generator. Find your code below and open it for what the manual says about its causes and what to do.

Error codes from p. 57

Code	What it means	Page
`DSP 0`	DSP not responding. The instrument must be power cycled	p. 57
`DSP 1`	DSP data bus error. The message is followed by a six digit (hex) code, corresponding to each data line (of 24) that is in error.	p. 57
`DSP 2`	DSP address bus and memory cell error. The message is followed by a six digit (hex) code, made up of three words. Bits 0-15 are DSP address lines 0-15. Bits 16-18 are set if there is an error on the X, Y or P memory spaces. Bits 19-21 are set if there is an error in the low (D0-7), middle (D8-15) or high (D16-23) bytes of the memory space.	p. 57
