NIDEK Le 1000 Error Codes

14 codes from page 150 of the manual

This is the list of error codes the NIDEK manual gives for the Le 1000 patternless edger. Find your code below and open it for what the manual says about its causes and what to do.

Error codes from p. 150

CodeWhat it meansPage
0001 Processing data transmission error p. 150
0002 Processing data reception error p. 150
0003 Noncompliant data reception (in VCA communication) p. 150
0107 Roughing is not completed. p. 150
0108 The wheel does not rotate at start of processing. p. 150
0201 The feelers are not initialized. p. 150
0204 The front surface cannot be measured after rear surface measurement. p. 150
0205 The data for lens measurement or the lens measurement result is abnormal. p. 150
0206 The data for first lens shape measurement is abnormal. p. 150
0207 The measurement data of the startpoint does not match that of the endpoint for lens shape measurement. p. 150
0208 The position of feelers is out of the measurable range during rear surface measurement. p. 150
0209 The position of feelers is out of the measurable range during front surface measurement. p. 150
0210 The lens thickness data for lens shape measurement is abnormal. p. 150
0301 The processing Y-axis data is abnormal. p. 150

Codes and descriptions are taken from the manufacturer’s manual; page numbers link to the PDF. ManualLib is not affiliated with NIDEK. Found a mistake? Report an error.
