AUK models by category
Featured AUK manuals
AUK SF20D400SD2 Ultrafast Recovery Rectifier Datasheet
The SF20D400SD2 is an ultrafast dual common‑cathode rectifier intended for free‑wheeling and clamping in switching power supplies, power inverters, DC/DC converters and other power‑switching applications.
Key features include a low forward voltage drop (typical 0.80 V at 10 A, 25 °C), 30 ns reverse recovery time, 400 V repetitive reverse voltage rating, and a D2‑PAK tape‑and‑reel package with a thermal resistance of 3.0 °C/W.
Covers: General Description · Features and Benefits · Applications · Ordering Information · Absolute Maximum Ratings · Thermal Characteristics
A K Semiconductor SRA2203 Datasheet
The SRA2203 PNP silicon transistor from A K Semiconductor features built‑in bias resistors that simplify circuit design and reduce part count, offering high packing density for compact applications. It is supplied in a TO‑92 package and includes detailed pin connections for emitter, collector and base.
Key electrical specifications include a maximum collector‑emitter voltage of –50 V, collector current of 100 mA, power dissipation of 200 mW, and a transition frequency of 200 MHz. The device operates over a wide temperature range from –55 °C to 150 °C and includes characteristic curves for voltage and current performance.
Covers: Descriptions · Features · Ordering Information · Pin Connections · Absolute Maximum Ratings · Electrical Characteristics
AK Semiconductor SM3418 LED Lamp Datasheet
The SM3418 (SM3418-(B)) LED lamp from AK Semiconductor features a green‑colored transparency lens, low power consumption, and a compact 3.8 mm × 3.0 mm package. The document lists mechanical dimensions, pin connections (anode and cathode), and two package styles – straight type and stopper type.
Key electrical data include absolute maximum ratings such as 85 mW power dissipation, 30 mA forward current, 4 V reverse voltage, and operating temperature range –25 °C to 85 °C. Typical performance values are given for forward voltage (2.8 V at 20 mA), luminous intensity (27 mcd), peak wavelength (570 nm), and spectrum bandwidth (30 nm). Characteristic diagrams illustrate forward current versus voltage, radiation patterns, and spectral distribution.
Covers: Features · Outline Dimensions · PINF Connections · Absolute Maximum Ratings · Electrical Characteristics · Characteristic Diagrams
AOK SDV708Q Variable Capacitance Diode Datasheet
The SDV708Q is a variable capacitance diode suitable for UHF band VCO applications, offering low series resistance and a wide capacitance tuning range. It is packaged in a SOD‑523 case and identified by the marking V8.
Key electrical characteristics include a continuous reverse voltage of 20 V, reverse current of 10 nA, total capacitance of 13.90‑16.10 pF at 2 V/1 MHz, and a series resistance of 0.6 Ω at 5 V/470 MHz. The device operates from –55 °C to 150 °C storage temperature and up to 150 °C junction temperature.
Covers: Features · Ordering Information · Outline Dimensions · Pin Connections · Absolute maximum ratings · Electrical Characteristics
Latest AUK manuals
AUK SF20D400SD2 Ultrafast Recovery Rectifier Datasheet
Datasheet 5 pages · 197 KB · ENThe AUK SF20D400SD2 is an ultrafast dual common‑cathode rectifier with low forward voltage drop and 30 ns reverse recovery time.
AUK SRA2202SF handbook
This document describes the features and characteristics of the SRA2202SF PNP silicon transistor, including its applications in switching, interface circuit, and driver circuit. It also highlights its built-in bias resistors, which simplify circuit design, reduce the quantity of parts and manufacturing process, and enable high packing density.
AUK BC817F NPN Silicon Transistor handbook
The BC817F is a NPN silicon transistor with high current, switching application, suitable for AF driver stage and low power output stage, and is a complementary pair of BC807F.
AUK BC807F PNP Silicon Transistor handbook
KST-2085-000 1 BC807F is a PNP silicon transistor suitable for high current and switching applications. It is suitable for AF driver stages and low power output stages, and is complementary to BC817F.
AUK SQ6601PT DATA SHEET
The SQ6601PT is a hybrid IC consisting of a power MOSFET and a controller IC, designed for Indirect feed-back Quasi-Resonant (including low frequency PRC) fly-back converter type SMPS (Switching Mode Power Supply) applications. This IC realizes high efficiency, low noise, downsizing and standardizing of a power supply system reducing external components count and simplifying the circuit designs.
AUK SPI5842 DATA SHEET
SPI5842 is an infrared photodiode product produced by KE. It features a peak sensitivity wavelength matching with infrared LED (λp=950nm), a package size of 4.8mm x 5.5mm, and is used in infrared remote controllers for TVs, VCRs, and audio equipment.
AUK S1117AQ/S1117-xxQ DATA SHEET
The S1117 series of positive adjustable and fixed regulators are designed to provide 1A with higher efficiency. All internal circuitry is designed to operate down to 1.3V input to output differential. Features include adjustable or fixed output, 1A output current, low dropout (1.3V), thermal shutdown protection, and fast transient response.
AUK Semiconductor SRC1202K NPN Silicon Transistor handbook
SRC1202K is a NPN Silicon Transistor with built-in bias resistors. It is suitable for switching application, interface circuit and driver circuit application.
AUK SY3318-V DATA SHEET
This document describes the features and characteristics of the KLY-0010-000 1 SY3318-V high brightness LED lamp. The LED lamp features colorless transparency lens, φ3mm(T-1) all plastic mold type, and super luminosity.
AUK S79xxPI Fixed-Negative-Voltage Regulator Data Sheet
S79xxPI series fixed negative voltage monolithic integrated circuit voltage regulators are designed to complement series S7800 in a wide range of applications.
AUK S78Lxx Positive-Voltage Regulators Data Sheet
This series of fixed-voltage monolithic integrated-circuit voltage regulators is designed for a wide range of applications. These applications include on-card regulation for elimination of Noise and distribution problems associated with single-point regulation. In addition, they can be used with power-pass elements to make high-current voltage regulators. Each of These regulators can deliver up to 100mA of output current. The internal limiting and thermal shutdown features of these regulators make them essentially immune to overload. When used as a replacement for a Zener diode-resistor combination, on effective improvement in output impedance can be obtained together with lover-bias current.
AUK STS9014 Data Sheet
STS9014 is a NPN silicon transistor with excellent hFE linearity and low noise.
AUK SDP530WKF DATA SHEET
This document describes the features of the KSD-2093-000 1 SDP530WKF attenuator diode, including low capacitance and low series resistance.
AUK Semiconductor SG5311 SG5311(B) Manual
The document describes the features of SG5311/SG5311(B) LED lamp, including colorless transparency, outline dimensions, pin connections, absolute maximum ratings, and electrical/optical characteristics.
AUK Semiconductor STS9013 handbook
The STS9013 is an NPN silicon transistor that is suitable for general purpose and switching applications. It has excellent hFE linearity and complements the STS9012.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in AUK manuals
What is the reverse recovery time of the SF20D400SD2?
The reverse recovery time is 30 ns.
From: AUK SF20D400SD2 Ultrafast Recovery Rectifier Datasheet
What package does the SF20D400SD2 use?
It is supplied in a D2‑PAK tape‑and‑reel package.
From: AUK SF20D400SD2 Ultrafast Recovery Rectifier Datasheet
What is the maximum collector current for the SRA2203?
The SRA2203 can handle up to 100 mA of collector current.
Which package does the SRA2203 use?
The transistor is supplied in a TO‑92 package.
What is the maximum forward current for the SM3418 LED lamp?
The absolute maximum forward current is 30 mA.
What is the peak wavelength of the emitted light?
The LED’s peak wavelength is 570 nm.
