Key facts
- Manuals
- 5
- Models
- 1
- Languages
- EN
- Last added
- 2026-09-28
Cornell Dubilier models by category
Featured Cornell Dubilier manuals
Cornell Dubilier Aluminum SMT Capacitors Application Guide
The Application Guide details the proper handling, soldering, and packaging of Cornell Dubilier aluminum SMT capacitors. It includes reflow temperature profiles, mechanical dimensions, tape and reel data, and recommended land patterns for PCB design.
Safety and reliability information is also covered, with tables of acceptable cleaning agents, hazardous solvents to avoid, and compatible coating materials. Following these guidelines helps ensure long‑term performance of the capacitors in assembled boards.
Covers: Reflow Soldering Temperature Profile · Case Dimensions · Tape Specifications · Reel Specifications · Land Pattern · Cleaning Agents
ROHS Type 361R 105 °C Miniature Industrial Grade Radial Leaded High-value High Ripple Low ESR ESL
The 361R series are miniature, industrial‑grade radial leaded capacitors designed for high‑value, high‑ripple applications. They operate from –40 °C up to +105 °C and are available with two‑lead (361R) or three‑lead (366R) configurations.
The document provides detailed specifications, case dimensions, part numbering, performance curves, and compliance information such as RoHS certification. Engineers can use the tables to select appropriate capacitance, voltage, and ESR values for their designs.
Covers: Outline Drawings · Specifications · Highlights · Operating Temperature · Rated Voltage · Capacitance
ROHS Compliant Type AVGA 40 °C to +105 °C High Capacitance SMT Aluminum Electrolytic Capacitors
The AVGA series from Cornell Dubilier offers high‑capacitance SMT aluminum electrolytic capacitors designed for filtering, bypassing, and power‑supply decoupling. They operate from –40 °C to +105 °C, are RoHS compliant, and can replace tantalum parts without voltage derating.
The document lists detailed electrical specifications, case codes, land‑pattern dimensions, and recommended soldering methods, including reflow profiles and hand‑solder limits for various case sizes.
Covers: Highlights · Specifications · Outline Drawings, Case Code & Dimensions · Ratings · Part Numbering System · Recommended Land Patterns
Cornell Dubilier 361R 105°C Miniature Radial Leaded Capacitor Datasheet
The 361R series are miniature, industrial‑grade radial‑lead electrolytic capacitors designed for high‑value, high‑ripple applications. They operate from –40 °C to +105 °C, offer low ESR and ESL, and are available with two or three leads.
The document provides detailed tables of case dimensions, part numbers, electrical ratings, ESR and ripple performance curves, and confirms RoHS compliance per EU Directive 2002/95/EC.
Covers: Outline Drawings · Highlights · Specifications · Case Dimensions · Part Numbering System · Typical Performance Curves
Latest Cornell Dubilier manuals
Cornell Dubilier Aluminum SMT Capacitors Application Guide
Application Note 5 pages · 202 KB · ENThis guide provides reflow soldering profiles, case dimensions, tape and reel specifications, cleaning agents, and coating recommendations for Cornell…
ROHS Type 361R 105 °C Miniature Industrial Grade Radial Leaded High-value High Ripple Low ESR ESL
Datasheet 5 pages · 287 KB · ENDatasheet for Cornell Dubilier 361R industrial‑grade radial leaded capacitors, covering specifications, dimensions, and performance data.
ROHS Compliant Type AVGA 40 °C to +105 °C High Capacitance SMT Aluminum Electrolytic Capacitors
Datasheet 6 pages · 197 KB · ENThe Cornell Dubilier AVGA datasheet provides specifications, dimensions, and soldering guidelines for high‑capacitance SMT aluminum electrolytic capacitors…
Cornell Dubilier 361R 105°C Miniature Radial Leaded Capacitor Datasheet
Datasheet 5 pages · 287 KB · ENThe Cornell Dubilier 361R datasheet details specifications for the 105 °C miniature radial‑lead capacitor, including ESR, ripple, dimensions and RoHS…
ROHS compliant Type 101C 55 °C to 105 °C Low-ESR Wide-Temperature Grade
Datasheet 9 pages · 349 KB · ENThe Cornell Dubilier 101C capacitor data sheet details its low‑ESR performance, wide temperature range (‑55 °C to 105 °C), ratings and dimensions.
Which document do I need?
Application Note
How to use the product for one specific task, with worked examples.
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Cornell Dubilier manuals
What is the recommended peak temperature for reflow soldering?
The guide specifies a peak temperature of 200 °C.
From: Cornell Dubilier Aluminum SMT Capacitors Application Guide
Which cleaning agents should be avoided with SMT aluminum capacitors?
Chlorine‑based halogenated solvents should not be used because they cause corrosion.
From: Cornell Dubilier Aluminum SMT Capacitors Application Guide
Is the 361R capacitor RoHS compliant?
Yes, it complies with the EU RoHS Directive 2002/95/EC.
How long can the 361R capacitor run at +105 °C?
It is rated for a load life of 4 000 hours at +105 °C.
What temperature range are AVGA capacitors rated for?
AVGA capacitors are rated for operation from –40 °C to +105 °C.
What is the rated voltage range for AVGA capacitors?
The series supports voltages from 6.3 Vdc up to 63 Vdc.
