Sipex SP6122 Low Voltage Buck Controller Datasheet
Datasheet 19 pages · 130 KB · EN
The Sipex SP6122 is a PFM minimum on-time controller designed for single 3V to 5.5V input supplies. It is engineered for small footprint applications and simplifies the transition from linear regulators to switcher solutions. Key features include high efficiency (greater than 90%), an optimized 20ns/1nF PFET output driver, and an accurate 1.5% reference.
Read onlineSipex SP6122 specifications
| Input Voltage Range | 3.0V to 5.5V |
|---|---|
| Output Current | 1A to 5A |
| Efficiency | Greater than 90% |
| Reference Accuracy | 1.5% |
| Package Type | Micro 8 |
| Oscillator Frequency | 210 kHz to 390 kHz |
| Soft Start Ramp Time | 3.5 ms |
| Sleep Mode Quiescent Current | 5uA |
All Sipex SP6122 documents by type
Datasheet 1
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the typical input voltage range for the SP6122?
The device is designed to work from a single 3.0V to 5.5V input supply.
What is the maximum output current capability?
The controller is ideal for applications requiring 1A to 5A output current.
