Key facts
- Brand
- ROHDE&SCHWARZ
- Model
- SMW200A
- Category
- Signal generator
- Industry
- Electronics
- Documents
- 2
- Languages
- ZH
- Last added
- 2026-10-19
Start here
Rohde & Schwarz SMW200A Vector Signal Generator Product Manual
The Rohde & Schwarz SMW200A is a high-performance vector signal generator designed for demanding applications requiring the generation of complex digital modulation signals. It supports various communication standards such as 5G, LTE-Advanced, and IEEE 802.11ac/ad. The device features an internal baseband with up to 2 GHz I/Q modulation bandwidth and is suitable for developing new broadband communication systems and validating 3G and 4G base stations. This manual is written in Chinese.
Read onlineRohde & Schwarz SMW200A specifications
| GNSS frequency bands | L1, L2, L5 |
|---|---|
| Number of GNSS channels (SMBV100B) | 6 to 60 |
| Number of RF outputs (SMBV100B) | 1 |
| Maximum simulated antennas (SMBV100B) | 1 |
| Maximum simulated vehicles | 1 (SMBV100B) / 2 (SMW200A) |
| Signal dynamics – Velocity max | 600 m/s (SMBV100B) / 10 000 m/s (SMW200A) |
| Interference generation | Yes |
Source: Rohde & Schwarz SMBV100B/SMW200A Satellite Navigation Test Platform User Manual
All Rohde & Schwarz SMW200A documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the frequency range of the SMW200A?
The frequency range extends from 100 kHz to 3 GHz, 6 GHz, 12.75 GHz, 20 GHz, 31.8 GHz or 40 GHz.
From: Rohde & Schwarz SMW200A Vector Signal Generator Product Manual
What is the maximum I/Q modulation bandwidth?
The internal baseband signal generator can produce up to 2 GHz of I/Q modulation bandwidth.
From: Rohde & Schwarz SMW200A Vector Signal Generator Product Manual
How many satellites can the SMBV100B simulate?
The SMBV100B can simulate up to 102 GNSS satellites.
From: Rohde & Schwarz SMBV100B/SMW200A Satellite Navigation Test Platform User Manual
What frequency bands does the SMW200A support?
The SMW200A supports L1, L2 and L5 GNSS frequency bands.
From: Rohde & Schwarz SMBV100B/SMW200A Satellite Navigation Test Platform User Manual
