Pro-face ST3000 Manuals

ManualLib has 3 documents for the Pro-face ST3000 (Automation control Equipment): 3 user manuals. Every file can be read online or downloaded as a PDF for free.

User Manual 3

Key facts

Model
ST3000
Industry
Industrial
Documents
3
Languages
EN · ZH
Last added
2026-09-28

Start here

Pro-face ST3000/ST3000W Series Standard HMI Operation Manual

Pro-face ST3000/ST3000W Series Standard HMI Operation Manual

User Manual 103 pages · 4.7 MB · ZH

The document is a user guide for the Pro-face ST3000/ST3000W series of standard programmable Human-Machine Interfaces (HMI). It covers essential safety precautions, operational procedures, installation steps, and maintenance requirements to ensure correct and safe usage. The manual includes specific warnings regarding electrical connections, environmental conditions, and LCD panel care. This manual is written in Chinese.

Read online

Pro-face ST3000 specifications

Operating temperature0 °C to 50 °C
Operating humidity10 %RH to 90 %RH (wet‑bulb ≤ 39 °C)
Input voltage (AC)AC 100 V–240 V, 50/60 Hz
Input voltage (DC)DC 19.2 V–28.8 V

Source: Pro-face ST3000 Series User Manual

All Pro-face ST3000 documents by type

User Manual 3

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Questions answered in these manuals

What is the operating temperature range for the ST3000 series?

The device may be used in environments from 0 °C up to 50 °C.

From: Pro-face ST3000 Series User Manual

What input voltages are supported by the ST3000 series?

It accepts AC 100 V to 240 V at 50/60 Hz or DC 19.2 V to 28.8 V.

From: Pro-face ST3000 Series User Manual

What should be done if the backlight of the ST fails?

Do not create touch panel switches that could cause injury or equipment damage, as the screen may still respond even when the backlight is broken.

From: Pro-face ST3000/ST3000W Series Standard HMI Operation Manual

Can the ST be used to control safety switches like emergency stops?

No, do not use touch screen switches for controlling equipment safety operations such as emergency stop switches; use separate hardware switches instead.

From: Pro-face ST3000/ST3000W Series Standard HMI Operation Manual

Can the backlight of the ST3000 be replaced?

No, the backlight is not replaceable; the whole unit should be replaced if the backlight fails.

From: Pro-face ST3000 Hardware Manual

What IP rating does the waterproof gasket meet?

The gasket meets an IP65 rating for moisture protection.

From: Pro-face ST3000 Hardware Manual
