Start here
X-10 Transmitter Receiver Instructions Manual
This manual provides instructions for installing the Pentair PG2000 pool light unit as a retrofit for existing systems. It details how to connect the XPFM modules, wire the power and signal lines, and secure the cover while observing safety warnings regarding electrical shock.
The document also covers operating procedures for the keychain remote control, including turning the bulb on/off and controlling the colorwheel function. Users can program specific House and Unit codes to customize their system settings.
Pentair PG2000 specifications
| Power Consumption | Approximately 200 Watts |
|---|---|
| Dimensions | 15 in. x 10% in. x 12 in. |
| Weight | 20 Ibs |
| Maximum Fiber Capacity | 600 FIBERworks fibers |
All Pentair PG2000 documents by type
Mounting, wiring and first power-up. Read it before the hardware goes in.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
Who should install the PG2000?
The PG2000 must be installed by a licensed or certified electrician in accordance with the National Electrical Code.
What is the minimum distance from the pool?
The unit should be located at least 5 feet from the pool, or the minimum distance required by local codes.
What battery is required for the keychain remote?
The manual specifies using a CR2025 Lithium 3V battery.
How far must the transceiver be from the pool?
The transceiver must be installed indoors at least 5 feet from the pool.
