Key facts
- Brand
- Kikusui
- Model
- TOS93 Series
- Category
- Industrial Supply
- Industry
- Industrial
- Documents
- 2
- Languages
- EN
- Last added
- 2026-10-01
Start here
Kikusui TOS93 Series Electrical Safety Analyzer User Manual
This manual covers the Kikusui TOS93 series electrical safety analyzer, describing its safety interlock, required accessories, and the various test functions such as withstanding voltage, insulation resistance, earth continuity, partial discharge, touch current, protective conductor current, and patient leakage current. It also explains how to configure the device, use the front‑panel controls, and perform remote control via SCPI commands.
Additional sections detail environmental requirements, power‑cord specifications, interface options (LAN, USB, RS232C), and warranty information. The document includes a table of contents, component names, safety warnings, and an appendix with specifications and troubleshooting guidance.
Kikusui TOS93 Series specifications
| Power plug types | NEMA5-15, CEE777, GB1002 |
|---|---|
| Rated input voltage / current | 125 Vac/10 A (NEMA5-15), 250 Vac/10 A (CEE777, GB1002) |
| Maximum ground‑continuity test current | 40 A (AC/DSC) – models TOS9302, TOS9303, TOS9303LC |
| Standard interfaces | LAN, USB, RS‑232C |
| Display | Color LCD screen |
Source: Kikusui TOS93 Series User Guide
All Kikusui TOS93 Series documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What power plug options are supplied with the TOS93 series?
The unit can be supplied with NEMA5‑15, CEE777, or GB1002 plugs, rated 125 Vac/10 A or 250 Vac/10 A.
Which test functions are available on the TOS9303LC model?
TOS9303LC supports ACW, DCW, IR, EC, and LC tests, covering high‑voltage, DC voltage, insulation resistance, ground continuity, and leakage current.
What does the safety interlock do when the TOS93 series is first powered on?
The safety interlock prevents any tests from being performed until the SIGNAL I/O plug is connected to release it.
From: Kikusui TOS93 Series Electrical Safety Analyzer User Manual
Which model supports the partial discharge test?
Only the TOS9301PD model includes the partial discharge measurement function.
From: Kikusui TOS93 Series Electrical Safety Analyzer User Manual
