Key facts
- Brand
- GermanPool
- Model
- GPS13
- Documents
- 2
- Languages
- EN · ZH
- Last added
- 2012-04-01
Start here
German Pool GPS13 Gas Water Heater Operation Manual
This manual covers the German Pool GPS13 gas water heater, a pool‑side hot‑water supply unit designed for residential use. It describes the heater’s main components, safety features, and technical specifications.
The document includes safety cautions, step‑by‑step installation, operation procedures, daily inspection, maintenance tasks, troubleshooting tips, specifications, and warranty information to help users install, operate, and service the heater safely.
GermanPool GPS13 specifications
| Power Supply | 220 V AC, 50 Hz |
|---|---|
| Maximum Heating Power | 28 kW (100.8 MJ/h) |
| Minimum Gas Consumption | 8 kW (28.8 MJ/h) |
| Water Pressure Range | 0.02–0.8 MPa (0.2–8 kgf/cm²) |
All GermanPool GPS13 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How can I set the desired hot water temperature?
Press the A+ or A‑ button on the control panel; the water temperature will reach the set value after about 10 seconds.
What safety devices are included in the heater?
The heater includes a flame failure device, overheat protection, hot‑water high‑limit device, electric fuse, pressure relief valve, and other safety sensors.
What is the body thickness of the German Pool GPS13 water heater?
The GPS13 has an ultra‑thin body thickness of 120 mm.
Which safety devices are included in the GPS13 water heater?
It includes a flame‑failure safety device, lightning surge protector, overheat prevention device, hot‑water high‑temperature limit device, electric fuse, and pressure‑relief valve.
