Start here
Danfoss TripleLynx 8/10/12.5/15 kW Solar Inverter Reference Manual
This manual covers the full range of Danfoss TripleLynx three‑phase solar inverters, describing safety and conformity requirements, functional overviews, and the approved power variants (8 kW, 10 kW, 12.5 kW, 15 kW). It details pre‑installation guidelines, mechanical and electrical connection procedures, and the setup of peripheral units such as GSM, RS485 and Ethernet interfaces.
Further sections explain the user interface, web‑server configuration, ancillary grid services, troubleshooting, maintenance, and technical data. Network topology options, torque specifications, and auxiliary interface specifications are also provided for installers and service technicians.
All Danfoss 15 kW documents by type
Instruction set, parameters and examples for configuring or programming the device.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What information does the VLT AutomationDrive FC 361 programming guide provide?
It provides information on controlling the VFD, accessing parameters, programming and troubleshooting.
What is the purpose of the brake resistor in the drive?
The brake resistor absorbs the regenerated braking power generated during dynamic braking.
